Name: LMZ31710RVQT
Brand: Texas Instruments
SKU: LMZ31710RVQT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments LMZ31710RVQT

Part No.:: LMZ31710RVQT

Manufacturer:: Texas Instruments

Package:: 42-BQFN Module

Datasheet:: LMZ31710RVQT.pdf

Description:: DC DC CONVERTER 0.6-5.5V 55W

In Stock:: 3110

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LMZ31710RVQT Specifications

Package/Case:
42-BQFN Module
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SIMPLE SWITCHER®
ProductStatus:
Active
Type:
Non-Isolated PoL Module
NumberofOutputs:
1
Voltage-Input(Min):
2.95V
Voltage-Input(Max):
17V
Voltage-Output1:
0.6 ~ 5.5V
Voltage-Output2:
-
Voltage-Output3:
-
Voltage-Output4:
-
Current-Output(Max):
10A
Power(Watts):
-
Voltage-Isolation:
-
Applications:
ITE (Commercial)
Features:
OCP, OTP, UVLO
OperatingTemperature:
-40°C ~ 85°C
Efficiency:
94%
MountingType:
Surface Mount
Size/Dimension:
0.40 L x 0.40 W x 0.17 H (10.2mm x 10.2mm x 4.4mm)
ControlFeatures:
ApprovalAgency:
