Analog Devices Inc./Maxim Integrated LM4040AIM3-3.0+

Part No.:: LM4040AIM3-3.0+

Manufacturer:: Analog Devices Inc./Maxim Integrated

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: LM4040AIM3-3.0+.pdf

Description:: IC VREF SHUNT 0.1% SOT23-3

In Stock:: 2318

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM4040AIM3-3.0+ Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
ReferenceType:
Shunt
OutputType:
Fixed
Voltage-Output(Min/Fixed):
3V
Voltage-Output(Max):
-
Current-Output:
15 mA
Tolerance:
±0.1%
TemperatureCoefficient:
100ppm/°C
Noise-01Hzto10Hz:
-
Noise-10Hzto10kHz:
45µVrms
Voltage-Input:
-
Current-Supply:
-
Current-Cathode:
67 µA
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

LM4040AIM3-3.0+ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM4040AIM3-3.0+ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM4040AIM3-3.0+ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM4040AIM3-3.0+ information

Views：

LM4040AIM3-3.0+ Typical application Circuitry

LM4040AIM3-3.0+

LM4040AIM3-3.0+ is a precision, micropower shunt voltage reference, offering a fixed 3.0V output with high stability and accuracy. It is designed for applications requiring a precise reference voltage, such as power supplies, battery-operated equipment, and data acquisition systems.

Application Scenarios

A typical application for the LM4040AIM3-3.0+ is in portable medical devices, where accurate voltage reference is crucial for sensor measurements and data acquisition accuracy, ensuring reliable monitoring of health parameters.

Parameter Features

- Fixed Voltage Reference: The LM4040AIM3-3.0+ provides a stable 3.0V reference voltage, essential for precision applications.

- Low Operating Current: Ideal for battery-operated devices due to its low power consumption, extending battery life.

- High Accuracy: Offers excellent stability and accuracy over temperature variations, critical for sensitive applications.

- Wide Operating Temperature Range: Suitable for a variety of environments due to its robust operating temperature range.

Circuit Connection Example: Portable Medical Device

Integrating the LM4040AIM3-3.0+ into a portable medical device involves key steps to ensure accurate sensor readings:

- Reference Voltage Setup: Connect the anode of the LM4040AIM3-3.0+ to the ground of the device. This configuration establishes the device as a shunt regulator, maintaining a stable voltage across it.

- Output Connection: Attach the cathode of the LM4040AIM3-3.0+ to the reference voltage input of the device's sensor or ADC. This setup provides a precise 3.0V reference, crucial for accurate measurements.

- Decoupling Capacitor: Place a decoupling capacitor (typically in the range of 0.1µF to 10µF) between the cathode of the LM4040AIM3-3.0+ and ground.This capacitor removes noise from the power source, which aids in maintaining the reference voltage.

- Load Current Consideration: Ensure the current through the LM4040AIM3-3.0+ is within its specified operating range, taking into account the current consumed by the connected sensor or ADC reference input.

Design Considerations

When designing with the LM4040AIM3-3.0+, it is crucial to consider the total current drawn through the voltage reference, ensuring it does not exceed the maximum specified current. To avoid overheating, thermal management should also be taken into consideration, particularly in small or enclosed designs. The physical layout of the PCB should minimize the path between the LM4040AIM3-3.0+ and the sensor or ADC to reduce potential noise interference, and a ground plane may be used to enhance noise immunity.

In summary, the LM4040AIM3-3.0+ is an excellent choice for providing a stable and accurate reference voltage in precision applications such as portable medical devices. By carefully addressing load current requirements, decoupling for noise reduction, and thermal considerations, designers can effectively utilize the LM4040AIM3-3.0+ in their circuits to ensure high accuracy and reliability.
