Texas Instruments LM393TL

Part No.:: LM393TL

Manufacturer:: Texas Instruments

Package:: 8-WFBGA, DSBGA

Datasheet:: LM393TL.pdf

Description:: IC COMPARATOR DUAL 8USMD

In Stock:: 2110

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM393TL Specifications

Package/Case:
8-WFBGA, DSBGA
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
Type:
General Purpose
NumberofElements:
2
OutputType:
CMOS, DTL, ECL, MOS, Open-Collector, TTL
Voltage-SupplySingle/Dual(±):
2V ~ 36V, ±1V ~ 18V
Voltage-InputOffset(Max):
5mV @ 30V
Current-InputBias(Max):
0.25µA @ 5V
Current-Output(Typ):
16mA @ 5V
Current-Quiescent(Max):
2.5mA
CMRRPSRR(Typ):
-
PropagationDelay(Max):
700ns
Hysteresis:
-
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

LM393TL this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM393TL price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM393TL to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM393TL information

Views：

LM393TL Typical application Circuitry

LM393TL

The LM393TL is a model from the LM393 series of integrated circuits, known for its dual differential comparators. This particular version is designed for precision applications requiring comparison functions. It operates effectively in various electronic configurations and is compatible with a wide range of power supply voltages.

1. Pin 1 (Output of Comparator A - LM393TL): In the LM393TL, this pin serves as the output for the first comparator. It provides the comparison result from the first comparator circuit.

2. Pin 2 (Inverting Input of Comparator A - LM393TL): This pin functions as the inverting input for the first comparator in the LM393TL. It is crucial for setting the reference level against which the non-inverting input is compared.

3. Pin 3 (Non-Inverting Input of Comparator A - LM393TL): Used for the non-inverting input of the first comparator, this pin in the LM393TL is essential for feeding the signal that is to be compared against the reference level on the inverting input.

4. Pin 4 (Ground or Negative Power Supply - LM393TL): The LM393TL utilizes this pin for grounding or connecting to the negative side of the power supply, integral for the operational stability of the comparator.

5. Pin 5 (Non-Inverting Input of Comparator B - LM393TL): As the non-inverting input for the second comparator, this pin in the LM393TL is significant for inputting the signal to be compared in the second comparator circuit.

6. Pin 6 (Inverting Input of Comparator B - LM393TL): This pin is the inverting input for the second comparator in the LM393TL, playing a key role in establishing the reference level for the second comparison.

7. Pin 7 (Output of Comparator B - LM393TL): This pin provides the output from the second comparator within the LM393TL.

8. Pin 8 (Positive Power Supply - LM393TL): Essential for powering the LM393TL, this pin connects to the positive power supply.

The LM393TL is frequently used in electronic designs for applications such as voltage level detection, window comparators, and other signal comparison tasks. Ensuring accurate connection of each pin according to the circuit's specific requirements, while taking into account the IC's characteristics like voltage range and input/output impedance, is crucial. A comprehensive understanding of each pin's function in the LM393TL is key to effectively utilizing this IC in electronic projects.
