Texas Instruments LM393PSRG4

Part No.:: LM393PSRG4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: LM393PSRG4.pdf

Description:: IC COMPARATOR DUAL DIFF 8SO

In Stock:: 2567

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM393PSRG4 Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
Differential
NumberofElements:
2
OutputType:
CMOS, MOS, Open-Drain, TTL
Voltage-SupplySingle/Dual(±):
2V ~ 36V, ±1V ~ 18V
Voltage-InputOffset(Max):
5mV @ 30V
Current-InputBias(Max):
0.25µA @ 5V
Current-Output(Typ):
20mA
Current-Quiescent(Max):
2.5mA
CMRRPSRR(Typ):
-
PropagationDelay(Max):
-
Hysteresis:
-
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

LM393PSRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM393PSRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM393PSRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM393PSRG4 information

Views：

LM393PSRG4 Typical application Circuitry

LM393PSRG4

The LM393PSRG4 is a specific model in the LM393 series of integrated circuits, well-regarded for their dual differential comparator functions. This series is widely used in electronics due to its exceptional ability to compare voltages, a crucial capability in many electronic applications. The LM393PSRG4 is particularly noted for its low power consumption and its flexibility to operate over a broad range of supply voltages, making it a versatile component in various electronic circuits.

1. Configuring the Power Supply Connections: The LM393PSRG4's functionality heavily relies on the correct setup of its power supply. This includes two main pins: Vcc, the positive supply voltage, and GND, the ground connection. The LM393PSRG4 is designed to work within a supply voltage range that typically spans from 2V to 36V for single supply systems, and ±1V to ±18V for dual supply modes. Ensuring that these pins are connected properly is crucial for the optimal performance of the IC.

2. Input Pin Configuration for Comparator Functionality: The dual comparator nature of the LM393PSRG4 is defined by its input pin arrangement. Each comparator in the LM393PSRG4 has an inverting (IN-) and a non-inverting (IN+) input. These inputs are vital for receiving the voltages to be compared. The inverting input is usually connected to a stable reference voltage, while the non-inverting input is used for connecting a variable voltage that is compared against the reference.

3. Setting Up Output Pins: The LM393PSRG4 comes with separate output pins for each comparator. These are "open-collector" outputs, meaning that in order to function properly, external pull-up resistors are needed. The output logic is designed such that it turns low when the voltage at the non-inverting input exceeds the voltage at the inverting input and remains high otherwise. This characteristic makes the LM393PSRG4 suitable for various digital interfacing applications.

4. Enhancing Circuit Stability and Reducing Noise: It is advisable to integrate a bypass capacitor in the circuit utilizing the LM393PSRG4. Positioned between the Vcc and GND pins, close to the IC, this capacitor aids in stabilizing the supply voltage and minimizing noise, enhancing the comparator's performance.

Incorporating the LM393PSRG4 into an electronic circuit requires an in-depth understanding of its pin layout and their specific functions. This knowledge is essential for effectively leveraging the LM393PSRG4 in a range of applications, from simple voltage level detection to more complex systems like oscillators and analog-to-digital converters.

In summary, the effective application of the LM393PSRG4 in electronic designs is contingent upon careful management of power supply connections, precise input signal routing, and appropriate configuration of the output stage. These factors are key to fully exploiting the capabilities of this versatile and efficient comparator IC in a broad spectrum of electronic applications.
