Texas Instruments LM339PWRG4

Part No.:: LM339PWRG4

Manufacturer:: Texas Instruments

Package:: 14-TSSOP (0.173, 4.40mm Width)

Datasheet:: LM339PWRG4.pdf

Description:: IC QUAD DIFF COMPARATOR 14-TSSOP

In Stock:: 2000

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM339PWRG4 Specifications

Package/Case:
14-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
Differential
NumberofElements:
4
OutputType:
CMOS, MOS, Open-Collector, TTL
Voltage-SupplySingle/Dual(±):
2V ~ 30V, ±1V ~ 15V
Voltage-InputOffset(Max):
5mV @ 30V
Current-InputBias(Max):
0.25µA @ 5V
Current-Output(Typ):
20mA
Current-Quiescent(Max):
2.5mA
CMRRPSRR(Typ):
-
PropagationDelay(Max):
-
Hysteresis:
-
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

LM339PWRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM339PWRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM339PWRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM339PWRG4 information

Views：

LM339PWRG4 Typical application Circuitry

LM339PWRG4

The LM339PWRG4 is part of the LM339 series, which is a set of low-power, quad differential comparators. These are widely used in electronic circuits for various applications, such as voltage level detection and signal conditioning. The LM339 series is designed for single or dual power supply operation.

1. Power Supply Connections: Pin 3 is the Ground (GND) connection for single supply operations, and in dual supply systems, it serves as the negative voltage supply. Pin 12 is the VCC or positive power supply pin. The LM339PWRG4 can be operated from a wide range of power supply voltages, from 2V to 36V for single supply or ±1V to ±18V for dual supply.

2. Comparator Inputs: Each comparator has an inverting (negative) and a non-inverting (positive) input. For the first comparator, pins 4 and 5 serve as inverting and non-inverting inputs, respectively. Similarly, for the second comparator, pins 6 and 7 are the inputs; for the third comparator, pins 8 and 9; and for the fourth comparator, pins 10 and 11.

3. Comparator Outputs: Since each comparator has an open-collector output, proper operation necessitates the use of an external pull-up resistor. The outputs from the first, second, third, and fourth comparators should be connected to pins 1, 2, 13, and 14.

In a typical application, you would connect the reference voltage to one of the inputs of each comparator and the signal to be compared to the other input. The output can then be used to drive a logic circuit, an LED, or any other indication or control element, depending on the application's needs.

Remember, when designing circuits with the LM339PWRG4, it's crucial to consider factors like input bias currents, output saturation voltage, and response time, which are detailed in the datasheet.

To summarize, the LM339PWRG4 is a versatile component in the LM339 comparator series, suitable for a wide range of applications in electronics, from simple voltage comparisons to more complex signal processing tasks.
