Texas Instruments LM2675MX-12

Part No.:: LM2675MX-12

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: LM2675MX-12.pdf

Description:: IC REG BUCK 12V 1A 8SOIC

In Stock:: 3791

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM2675MX-12 Specifications

Packaging:
Tape & Reel (TR)
Series:
SIMPLE SWITCHER®
ProductStatus:
Obsolete
Function:
Step-Down
OutputConfiguration:
Positive
Topology:
Buck
OutputType:
Fixed
NumberofOutputs:
1
Voltage-Input(Min):
6.5V
Voltage-Input(Max):
40V
Voltage-Output(Min/Fixed):
12V
Voltage-Output(Max):
-
Current-Output:
1A
Frequency-Switching:
260kHz
SynchronousRectifier:
No
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount

LM2675MX-12 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM2675MX-12 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM2675MX-12 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM2675MX-12 information

Views：

LM2675MX-12 Typical application Circuitry

LM2675MX-12 is an integrated circuit (IC) developed by Texas Instruments. As part of the SIMPLE SWITCHER® series, it is a step-down voltage regulator that provides a regulated output of 12V.

Functional Overview: LM2675MX-12 acts as a buck regulator, reducing a higher input voltage to a lower, regulated output voltage. It provides a constant output of 12V with an input voltage range from 8V to 40V.

Key Parameters:

1. Efficiency: The LM2675MX-12 shows impressive efficiency, making it ideal for power-sensitive applications.

2. Frequency Operation: Operating at a fixed frequency of 260 kHz, it reduces noise and simplifies design considerations in RF sensitive applications.

3. Protection Features: The chip incorporates protection against situations like overcurrent and thermal overload.

The LM2675MX-12 can be used in various settings, including power regulation for consumer products, distributed power systems, and pre-regulation for linear regulators.

Consider the application of LM2675MX-12 in a distributed power system. A step-by-step tutorial for connecting the circuit is provided below:

1. Input Voltage (Pin 6): The input voltage within the permissible range is to be applied to the VIN pin (Pin 6).

2. Ground Connection (Pin 2): The GND pin (Pin 2) should be linked to the ground of your system.

3. Output Voltage (Pin 5): The regulated output voltage is derived from the SW pin (Pin 5). An inductor is required between this pin and the load.

4. ON/OFF Control (Pin 1): The ON/OFF pin (Pin 1) can be grounded for continuous operation of the regulator. Driving this pin high will shut off the regulator.

Designing with the LM2675MX-12 involves several considerations:

- Component Selection: Choosing appropriate passive components, such as the inductor and capacitors, is crucial for the overall performance and stability of the system.

- Thermal Management: Despite the LM2675MX-12 being a high-efficiency IC, handling the dissipated heat, particularly under high load conditions, is necessary to prevent thermal overload.

- PCB Layout: Regulator performance can be strongly impacted by the printed circuit board (PCB) layout, which can change factors like noise, stability, and efficiency.

For an in-depth understanding and to make the right design choices with the LM2675MX-12, always consult the datasheet of the IC.
