Lattice Semiconductor Corporation LC4128V-75TN144C

Part No.:: LC4128V-75TN144C

Manufacturer:: Lattice Semiconductor Corporation

Package:: 144-LQFP

Datasheet:: LC4128V-75TN144C.pdf

Description:: IC CPLD 128MC 7.5NS 144TQFP

In Stock:: 2379

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LC4128V-75TN144C Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
ispMACH® 4000V
ProductStatus:
Active
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
7.5 ns
VoltageSupply-Internal:
3V ~ 3.6V
NumberofLogicElements/Blocks:
8
NumberofMacrocells:
128
NumberofGates:
-
NumberofI/O:
96
OperatingTemperature:
0°C ~ 90°C (TJ)
MountingType:
Surface Mount
