STMicroelectronics L9301

Part No.:: L9301

Manufacturer:: STMicroelectronics

Package:: PowerSSO-36 EPD

Datasheet:: L9301.pdf

Description:: IC PWR DRIVER N-CHANNEL PWRSSO36

In Stock:: 2421

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

L9301 Specifications

Package/Case:
PowerSSO-36 EPD
Packaging:
Tube
Series:
Automotive, AEC-Q100
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
12
Ratio-Input:Output:
-
OutputConfiguration:
High Side or Low Side
OutputType:
N-Channel
Interface:
SPI, Parallel
Voltage-Load:
5V ~ 18V
Voltage-Supply(Vcc/Vdd):
4.75V ~ 5.25V
Current-Output(Max):
-
RdsOn(Typ):
-
InputType:
-
Features:
-
FaultProtection:
Current Limiting (Fixed), Over Temperature
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
