Texas Instruments ISO7240CDWRG4

Part No.:: ISO7240CDWRG4

Manufacturer:: Texas Instruments

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: ISO7240CDWRG4.pdf

Description:: DGTL ISO 2500VRMS 4CH GP 16SOIC

In Stock:: 3621

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ISO7240CDWRG4 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
Technology:
Capacitive Coupling
Type:
General Purpose
IsolatedPower:
No
NumberofChannels:
4
Inputs-Side1/Side2:
4/0
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
25Mbps
PropagationDelaytpLH/tpHL(Max):
42ns, 42ns
PulseWidthDistortion(Max):
2.5ns
Rise/FallTime(Typ):
2ns, 2ns
Voltage-Supply:
3.15V ~ 5.5V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
