Texas Instruments ISO6740QDWRQ1

Part No.:: ISO6740QDWRQ1

Manufacturer:: Texas Instruments

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:

Description:: AUTOMOTIVE, GENERAL-PURPOSE, QUA

In Stock:: 2637

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ISO6740QDWRQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100, ISO674x
ProductStatus:
Active
Technology:
Capacitive Coupling
Type:
CAN
IsolatedPower:
No
NumberofChannels:
4
Inputs-Side1/Side2:
4/0
ChannelType:
Unidirectional
Voltage-Isolation:
5000Vrms
CommonModeTransientImmunity(Min):
100kV/µs
DataRate:
50Mbps
PropagationDelaytpLH/tpHL(Max):
18ns, 18ns
PulseWidthDistortion(Max):
7ns
Rise/FallTime(Typ):
2.6ns, 2.6ns
Voltage-Supply:
2.25V ~ 5.5V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
