Analog Devices Inc. HMC798ALC4TR-R5

Part No.:: HMC798ALC4TR-R5

Manufacturer:: Analog Devices Inc.

Package:: 24-CLCC Exposed Pad

Datasheet:: HMC798ALC4TR-R5.pdf

Description:: IC MMIC MIXER SUB-HARM 24SMD

In Stock:: 3825

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC798ALC4TR-R5 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
RFType:
VSAT
Frequency:
24GHz ~ 34GHz
NumberofMixers:
1
Gain:
-
NoiseFigure:
-
SecondaryAttributes:
-
Current-Supply:
95mA
Voltage-Supply:
5V
MountingType:
Surface Mount
