Broadcom Limited HFBR-1527Z

Part No.:: HFBR-1527Z

Manufacturer:: Broadcom Limited

Package:

Datasheet:: HFBR-1527Z.pdf

Description:: FIBER OPTIC TX 125 MBD 650N

In Stock:: 2629

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HFBR-1527Z Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
Wavelength:
650nm
SpectralBandwidth:
21nm
Voltage-Forward(Vf)(Typ):
2.1V
Current-DCForward(If)(Max):
80 mA
Voltage-DCReverse(Vr)(Max):
3 V
Capacitance:
60 pF
