Broadcom Limited HCPL-092J-500E

Part No.:: HCPL-092J-500E

Manufacturer:: Broadcom Limited

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: HCPL-092J-500E.pdf

Description:: DGTL ISO 2500VRMS 4CH GP 16SOIC

In Stock:: 2855

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HCPL-092J-500E Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Technology:
GMR (Giant Magnetoresistive)
Type:
General Purpose
IsolatedPower:
No
NumberofChannels:
4
Inputs-Side1/Side2:
3/1
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
15kV/µs
DataRate:
110MBd
PropagationDelaytpLH/tpHL(Max):
15ns, 15ns
PulseWidthDistortion(Max):
3ns
Rise/FallTime(Typ):
1ns, 1ns
Voltage-Supply:
3V ~ 5.5V
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount
