FNB41560 Typical application Circuitry

FNB41560

The FNB41560 is an advanced Motion SPM® 45 series module developed by Fairchild/ON Semiconductor. It is an Intelligent Power Module (IPM) that provides a high-performance inverter solution for appliance and industrial motor drives.

FNB41560 Features:

- Integrated Drive, Protection, and System Control Functions: The FNB41560 combines the optimized gate drive of the built-in IGBTs (Insulated Gate Bipolar Transistors) with multiple protection features including under-voltage lockouts, over-current shutdown, fault reporting, and temperature sensing.

- Power Ratings: This module operates at a supply voltage of 600V with a continuous collector current of 15A. These ratings make it suitable for many high-power applications.

- Package: The FNB41560 is available in a 29-lead, surface-mount DIP (Dual Inline Package). This package is designed for high-power applications and has good thermal performance.

>Applications of FNB41560:

The FNB41560 is used in various applications like air conditioners, washing machines, refrigeration systems, and servo drives.

Example Circuit Connection - Motor Drive:

1. Power Supply Connections: Pins Vcc and Vbs (Pins 1, 2, 14, and 27) of the FNB41560 are connected to the positive terminal of the power supply, while GND and COM (Pins 15, 16, 28, and 29) are connected to the negative terminal.

2. Input Signal Connections: Input signals are applied to IN-U, IN-V, and IN-W (Pins 8, 9, and 10 respectively). These inputs control the operation of the three phases of the motor.

3. Fault Signal: FAULT (Pin 6) provides the fault signal. It goes low under fault conditions such as over-current or over-temperature.

4. PWM Input: The PWM (Pulse Width Modulation) signal, which controls the speed of the motor, is fed to the PWM (Pin 7) of the FNB41560.

5. Motor Connections: The outputs U, V, and W (Pins 11, 12, and 13) are connected to the three-phase motor windings.

Design Considerations with FNB41560:

While designing a circuit with FNB41560, a few key points need to be kept in mind:

- Thermal Management: Due to its high power operation, the FNB41560 generates significant heat. Proper heat sinks or other cooling methods should be implemented to prevent overheating.

- Protection Features: The module includes several protection features. It's important to fully understand these features and use them effectively to prevent damage to the module and other parts of the circuit.

- Gate Drive Circuit: The FNB41560 requires a gate drive circuit to operate the IGBTs. The design of this circuit should be optimized to ensure fast and efficient operation of the IGBTs.

- Decoupling Capacitors:To filter out high-frequency noise and offer a steady power supply, decoupling capacitors should be placed close to the power pins (Vcc and Vbs).

FNB41560 information

FNB41560 Specifications

Package/Case:
26-SPM
Packaging:
Bulk,Tube
Series:
Motion SPM® 45
ProductStatus:
Not For New Designs
Type:
IGBT
Configuration:
3 Phase
Current:
15 A
Voltage:
600 V
Voltage-Isolation:
2000Vrms
MountingType:
Through Hole
