Espressif Systems ESP32-S2-MINI-1U-N4

Part No.:: ESP32-S2-MINI-1U-N4

Manufacturer:: Espressif Systems

Package:

Datasheet:: ESP32-S2-MINI-1U-N4.pdf

Description:: SMD MODULE W/IPEX ANT CONNECTOR

In Stock:: 2615

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ESP32-S2-MINI-1U-N4 Specifications

Package/Case:
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
ESP32
ProductStatus:
Not For New Designs
RFFamily/Standard:
WiFi
Protocol:
802.11b/g/n
Modulation:
-
Frequency:
2.412GHz ~ 2.484GHz
DataRate:
150Mbps
Power-Output:
19.5dBm
Sensitivity:
-97dBm
SerialInterfaces:
ADC, GPIO, I²C, I²S, SPI, PWM, UART, USB
AntennaType:
Antenna Not Included
UtilizedIC/Part:
ESP32-S2
MemorySize:
128kB ROM, 320kB SRAM
Voltage-Supply:
3V ~ 3.6V
Current-Receiving:
63mA ~ 68mA
Current-Transmitting:
160mA ~ 310mA
MountingType:
Surface Mount
