Intel EPM7128STC100-6

Part No.:: EPM7128STC100-6

Manufacturer:: Intel

Package:: 100-TQFP

Datasheet:: EPM7128STC100-6.pdf

Description:: IC CPLD 128MC 6NS 100TQFP

In Stock:: 2573

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPM7128STC100-6 Specifications

Package/Case:
100-TQFP
Packaging:
Tray
Series:
MAX® 7000S
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
6 ns
VoltageSupply-Internal:
4.75V ~ 5.25V
NumberofLogicElements/Blocks:
8
NumberofMacrocells:
128
NumberofGates:
2500
NumberofI/O:
84
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
