Intel EPM7128SLC84-10N

Part No.:: EPM7128SLC84-10N

Manufacturer:: Intel

Package:: 84-LCC (J-Lead)

Datasheet:: EPM7128SLC84-10N.pdf

Description:: IC CPLD 128MC 10NS 84PLCC

In Stock:: 3289

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPM7128SLC84-10N Specifications

Package/Case:
84-LCC (J-Lead)
Packaging:
Tube
Series:
MAX® 7000S
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
10 ns
VoltageSupply-Internal:
4.75V ~ 5.25V
NumberofLogicElements/Blocks:
8
NumberofMacrocells:
128
NumberofGates:
2500
NumberofI/O:
68
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
