Intel EPM3128ATC144-7

Part No.:: EPM3128ATC144-7

Manufacturer:: Intel

Package:: 144-LQFP

Datasheet:: EPM3128ATC144-7.pdf

Description:: IC CPLD 128MC 7.5NS 144TQFP

In Stock:: 3896

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPM3128ATC144-7 Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
MAX® 3000A
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
7.5 ns
VoltageSupply-Internal:
3V ~ 3.6V
NumberofLogicElements/Blocks:
8
NumberofMacrocells:
128
NumberofGates:
2500
NumberofI/O:
96
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
