Intel EPM240F100C5NAB

Part No.:: EPM240F100C5NAB

Manufacturer:: Intel

Package:: 100-LBGA

Datasheet:

Description:: IC CPLD 192MC 4.7NS 100FBGA

In Stock:: 2391

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPM240F100C5NAB Specifications

Package/Case:
100-LBGA
Packaging:
Tray
Series:
MAX® II
ProductStatus:
Active
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
7.5 ns
VoltageSupply-Internal:
2.375V ~ 2.625V, 3V ~ 3.6V
NumberofLogicElements/Blocks:
240
NumberofMacrocells:
192
NumberofGates:
-
NumberofI/O:
80
OperatingTemperature:
0°C ~ 85°C (TJ)
MountingType:
Surface Mount
