Intel EPF10K70RC240-4

Part No.:: EPF10K70RC240-4

Manufacturer:: Intel

Package:: 240-BFQFP Exposed Pad

Datasheet:: EPF10K70RC240-4.pdf

Description:: IC FPGA 189 I/O 240RQFP

In Stock:: 3578

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPF10K70RC240-4 Specifications

Package/Case:
240-BFQFP Exposed Pad
Packaging:
Tray
Series:
FLEX-10K®
ProductStatus:
Obsolete
NumberofLABs/CLBs:
468
NumberofLogicElements/Cells:
3744
TotalRAMBits:
18432
NumberofI/O:
189
NumberofGates:
118000
Voltage-Supply:
4.75V ~ 5.25V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 70°C (TA)
