Intel EPCQ16SI8N

Part No.:: EPCQ16SI8N

Manufacturer:: Intel

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: EPCQ16SI8N.pdf

Description:: IC CONFIG DEVICE 16MBIT 8SOIC

In Stock:: 2441

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EPCQ16SI8N Specifications

Packaging:
Tube
Series:
EPCQ
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
MemorySize:
16Mb
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

EPCQ16SI8N this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including EPCQ16SI8N price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for EPCQ16SI8N to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

EPCQ16SI8N information

Views：

EPCQ16SI8N Typical application Circuitry

EPCQ16SI8N

EPCQ16SI8N is a Serial Configuration Device from Intel (formerly Altera), designed for use with Intel's FPGA devices. When the FPGA is powered on, configuration data that are needed to set it up are stored there. This device is essential for systems where the FPGA needs to be reconfigured with specific logic or functionality after each power cycle.

Application Scenarios

EPCQ16SI8N is predominantly used in systems that incorporate Intel FPGA devices, such as embedded systems, digital signal processing units, communication systems, and industrial control systems. A specific application scenario could be in an embedded system for image processing, where EPCQ16SI8N stores the configuration data for the FPGA that performs image analysis algorithms.

Parameter Features

The EPCQ16SI8N offers features like a 16-Mbit memory size, support for the Serial Peripheral Interface (SPI) protocol, high reliability with a minimum of 100,000 erase/write cycles, and data retention of up to 20 years.Due to its tiny package size, it can be used in applications where space is limited.

Circuit Connection Example: FPGA-based Image Processing System

In an FPGA-based image processing system, EPCQ16SI8N is used to store the configuration data for the FPGA. Key considerations for the circuit connection would include:

- Power Supply Connections: Connect the VCC pin of EPCQ16SI8N to a stable 3.3V power supply, ensuring the GND pin is connected to the system ground. To provide a consistent supply and filter out noise, use decoupling capacitors close to the VCC pin.

- SPI Interface: Connect the SPI pins (DATA0, DCLK, nCSO, and DATA1 for bidirectional data transfer) of EPCQ16SI8N to the corresponding SPI interface pins on the FPGA. This setup enables the FPGA to read its configuration data from EPCQ16SI8N upon power-up.

- Configuration Pin: The nCONFIG pin on the FPGA should be connected to a pull-up resistor to ensure it remains high during normal operation, but can be pulled low to initiate reconfiguration.

- Status Pins: Connect the nSTATUS and CONF_DONE pins from the FPGA to EPCQ16SI8N to monitor the status of the configuration process and indicate when configuration is complete.

When designing circuits with EPCQ16SI8N, consider the read speed required by the FPGA to ensure the configuration data can be loaded quickly enough during system startup. Additionally, ensure that the PCB layout minimizes noise and signal integrity issues, especially on the SPI interface lines, to ensure reliable configuration of the FPGA. Properly securing the SPI lines and ensuring stable power supply conditions are also critical for the successful operation of the system.
