Thales DIS (formerly Gemalto) EHS5-E REL.4

Part No.:: EHS5-E REL.4

Manufacturer:: Thales DIS (formerly Gemalto)

Package:

Datasheet:: EHS5-E REL.4.pdf

Description:: RF TXRX MOD CELL 2G/3G EU SMD

In Stock:: 3568

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

EHS5-E REL.4 Specifications

Package/Case:
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Cinterion EHS5
ProductStatus:
Active
RFFamily/Standard:
Cellular
Protocol:
EDGE, GPRS, GSM, HSPA+, UMTS
Modulation:
16-QAM
Frequency:
900MHz, 1.8GHz, 2.1GHz
DataRate:
7.2Mbps
Power-Output:
33dBm
Sensitivity:
-
SerialInterfaces:
ADC, GPIO, I²C, I²S, PCM, SPI, UART, USB
AntennaType:
Antenna Not Included
UtilizedIC/Part:
Intel XMM 6260
MemorySize:
10MB Flash, 10MB RAM
Voltage-Supply:
3.3V ~ 4.5V
Current-Receiving:
-
Current-Transmitting:
30mA ~ 710mA
MountingType:
Surface Mount
