NXP USA Inc. DSPB56362AG120R2

Part No.:: DSPB56362AG120R2

Manufacturer:: NXP USA Inc.

Package:

Datasheet:: DSPB56362AG120R2.pdf

Description:: LEAD FREE DSP56362

In Stock:: 3673

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DSPB56362AG120R2 Specifications

Package/Case:
Packaging:
Tape & Reel (TR)
Series:
DSP56K/Symphony
ProductStatus:
Obsolete
Type:
Audio Processor
Interface:
Host Interface, I²C, SAI, SPI
ClockRate:
120MHz
Non-VolatileMemory:
ROM (126kB)
On-ChipRAM:
42kB
Voltage-I/O:
3.30V
Voltage-Core:
3.30V
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
