Texas Instruments DS90UB941ASRTDTQ1

Part No.:: DS90UB941ASRTDTQ1

Manufacturer:: Texas Instruments

Package:: 64-VFQFN Exposed Pad

Datasheet:: DS90UB941ASRTDTQ1.pdf

Description:: INTERFACE IC MISC

In Stock:: 3540

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DS90UB941ASRTDTQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Function:
Serializer
DataRate:
1.5Gbps
InputType:
MIPI DSI
OutputType:
FPD-Link III, LVDS
NumberofInputs:
4
NumberofOutputs:
2
Voltage-Supply:
1.045V ~ 1.155V, 1.71V ~ 1.89V
OperatingTemperature:
-40°C ~ 105°C (TA)
MountingType:
Surface Mount
