Analog Devices Inc./Maxim Integrated DS9034PCX

Part No.:: DS9034PCX

Manufacturer:: Analog Devices Inc./Maxim Integrated

Package:: 34-PowerCap™ Module

Datasheet:: DS9034PCX.pdf

Description:: PCM W/CRYSTAL NV SRAM SNAP-ON

In Stock:: 3858

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DS9034PCX Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
Function:
Back-Up Management
BatteryChemistry:
Lithium Cell
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount
