Texas Instruments DAC8043UCG4

Part No.:: DAC8043UCG4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: DAC8043UCG4.pdf

Description:: IC DAC 12BIT A-OUT 8SOIC

In Stock:: 3645

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DAC8043UCG4 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
NumberofBits:
12
NumberofD/AConverters:
1
SettlingTime:
1µs
OutputType:
Current - Unbuffered
DifferentialOutput:
No
DataInterface:
SPI
ReferenceType:
External
Voltage-SupplyAnalog:
5V
Voltage-SupplyDigital:
5V
INL/DNL(LSB):
±0.5 (Max), ±0.5 (Max)
Architecture:
Multiplying DAC
OperatingTemperature:
-40°C ~ 85°C
