Texas Instruments DAC7750IPWP

Part No.:: DAC7750IPWP

Manufacturer:: Texas Instruments

Package:: 24-TSSOP (0.173, 4.40mm Width) Exposed Pad

Datasheet:: DAC7750IPWP.pdf

Description:: IC DAC 12BIT A-OUT 24HTSSOP

In Stock:: 3422

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DAC7750IPWP Specifications

Package/Case:
24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
1
SettlingTime:
25µs (Typ)
OutputType:
Current - Buffered
DifferentialOutput:
No
DataInterface:
SPI, DSP
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
10V ~ 36V
Voltage-SupplyDigital:
2.7V ~ 5.5V
INL/DNL(LSB):
-, ±1 (Max)
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 125°C
