Texas Instruments DAC7724U

Part No.:: DAC7724U

Manufacturer:: Texas Instruments

Package:: 28-SOIC (0.295, 7.50mm Width)

Datasheet:: DAC7724U.pdf

Description:: IC DAC 12BIT V-OUT 28SOIC

In Stock:: 2496

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DAC7724U Specifications

Package/Case:
28-SOIC (0.295, 7.50mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
4
SettlingTime:
10µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
Parallel
ReferenceType:
External
Voltage-SupplyAnalog:
±14.25V ~ 15.75V
Voltage-SupplyDigital:
5V
INL/DNL(LSB):
±2 (Max), ±1 (Max)
Architecture:
R-2R
OperatingTemperature:
-40°C ~ 85°C
