Texas Instruments DAC7612UB

Part No.:: DAC7612UB

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: DAC7612UB.pdf

Description:: IC DAC 12BIT V-OUT 8SOIC

In Stock:: 3870

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DAC7612UB Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
2
SettlingTime:
7µs (Typ)
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
SPI
ReferenceType:
Internal
Voltage-SupplyAnalog:
5V
Voltage-SupplyDigital:
5V
INL/DNL(LSB):
±0.25, ±0.25
Architecture:
R-2R
OperatingTemperature:
-40°C ~ 85°C
