National Semiconductor DAC121S101CIMK-NS

Part No.:: DAC121S101CIMK-NS

Manufacturer:: National Semiconductor

Package:: SOT-23-6 Thin, TSOT-23-6

Datasheet:: DAC121S101CIMK-NS.pdf

Description:: DAC, 1 FUNC, SERIAL INPUT LOADIN

In Stock:: 555

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DAC121S101CIMK-NS Specifications

Package/Case:
SOT-23-6 Thin, TSOT-23-6
Packaging:
Bulk
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
1
SettlingTime:
10µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
DSP, Microwire, QSPI, SPI
ReferenceType:
Supply
Voltage-SupplyAnalog:
2.7V ~ 5.5V
Voltage-SupplyDigital:
2.7V ~ 5.5V
INL/DNL(LSB):
±2.6, ±1
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 105°C
