What is the Additional Feature ?

Name: BTS711L1NT
Brand: Infineon Technologies
SKU: BTS711L1NT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Infineon Technologies BTS711L1NT

Part No.:: BTS711L1NT

Manufacturer:: Infineon Technologies

Package:: PG-DSO-20-31

Datasheet:

Description:: IC PWR SWITCH N-CHAN 1:1 DSO-20

In Stock:: 2085

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BTS711L1NT Specifications

Package/Case:
PG-DSO-20-31
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, PROFET®
ProductStatus:
Obsolete
SwitchType:
General Purpose
NumberofOutputs:
4
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
5V ~ 34V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
1.7A
RdsOn(Typ):
165mOhm
InputType:
Non-Inverting
Features:
Auto Restart, Status Flag
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount

BTS711L1NT this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including BTS711L1NT price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for BTS711L1NT to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

BTS711L1NT information

Views：

BTS711L1NT Typical application Circuitry

BTS711L1NT

The BTS711L1NT is a type of smart high-side power switch, primarily designed for controlling high-current loads. It typically finds applications in automotive and industrial environments due to its ability to switch and control power efficiently and safely. This IC is known for its multiple output channels and integrated protective features, making it highly versatile.

Application Scenario: Automotive Power Distribution System

Use Case: Controlling various loads like lights, motors, and heaters in a vehicle.

Key Parameters of BTS711L1NT:

- Quad High-Side Power Switch: Capable of controlling four separate loads.

- Load Current Capacity: Designed to handle significant currents for automotive applications.

- Integrated Protective Features: Overcurrent, overvoltage, and thermal protection.

- Low Quiescent Current: Efficient power consumption in standby mode.

Circuit Design: Control of Automotive Interior Lights

Detailed Circuit Implementation:

1. Connection to Car Battery: Connect the vehicle's 12V battery to the Vbb pin (Pin 1) of the BTS711L1NT.

2. Interior Light Connections: Attach four different interior lights to OUT1 (Pin 2), OUT2 (Pin 3), OUT3 (Pin 4), and OUT4 (Pin 5).

3. System Grounding: Link the GND pin (Pin 6) to the car's ground.

4. Control Inputs: Wire the control inputs IN1 (Pin 7), IN2 (Pin 8), IN3 (Pin 9), and IN4 (Pin 10) to the vehicle's body control module (BCM).

Design Considerations:

1. Light Current Ratings: Ensure the interior lights' current requirements are within the BTS711L1NT's specifications.

2. BCM Signal Compatibility: Check that the BCM's output signals align with the IC's input thresholds.

3. Heat Dissipation Strategy: Consider thermal management due to current flow through the IC.

4. Leveraging Protective Circuits: Utilize the IC's built-in protection features for electrical safety.

5. Minimizing EMI: Implement EMI reduction strategies, critical in automotive electronics.

6. Voltage Stability and Fluctuations: Ensure consistent voltage supply, especially under varying engine conditions.

7. Diagnostic Capabilities: Utilize diagnostic outputs for real-time monitoring and fault detection.

8. Automotive Grade Components: Use connectors and wiring suitable for automotive standards.

This application highlights the BTS711L1NT's use in an automotive interior lighting system, demonstrating its ability to manage multiple loads, such as interior lights, efficiently. Emphasis on aspects like BCM compatibility, EMI mitigation, and the use of automotive-grade components underscores the IC's suitability for automotive electrical systems.
