Infineon Technologies BTS621L1E3128ABUMA1

Part No.:: BTS621L1E3128ABUMA1

Manufacturer:: Infineon Technologies

Package:: PG-TO263-7-2

Datasheet:: BTS621L1E3128ABUMA1.pdf

Description:: IC PWR SWITCH N-CHAN 1:1 TO263-7

In Stock:: 3689

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BTS621L1E3128ABUMA1 Specifications

Package/Case:
PG-TO263-7-2
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PROFET®
ProductStatus:
Not For New Designs
SwitchType:
General Purpose
NumberofOutputs:
2
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
5V ~ 34V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
4.4A
RdsOn(Typ):
80mOhm
InputType:
-
Features:
Auto Restart, Status Flag
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
