Infineon Technologies BSP752RXUMA2

Part No.:: BSP752RXUMA2

Manufacturer:: Infineon Technologies

Package:: PG-DSO-8-6

Datasheet:: BSP752RXUMA2.pdf

Description:: IC PWR SWITCH N-CHAN 1:1 PDSO-8

In Stock:: 3877

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSP752RXUMA2 Specifications

Package/Case:
PG-DSO-8-6
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
miniPROFET®
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
6V ~ 52V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
1.3A
RdsOn(Typ):
150mOhm
InputType:
Non-Inverting
Features:
-
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
