Texas Instruments BQ24100RHLR

Part No.:: BQ24100RHLR

Manufacturer:: Texas Instruments

Package:: 20-VFQFN Exposed Pad

Datasheet:: BQ24100RHLR.pdf

Description:: IC BATT CHG LI-ION 1CELL 20VQFN

In Stock:: 2497

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BQ24100RHLR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
bqSWITCHER™
ProductStatus:
Active
BatteryChemistry:
Lithium Ion/Polymer
NumberofCells:
1
Current-Charging:
Constant - Programmable
ProgrammableFeatures:
Current, Timer
FaultProtection:
Over Temperature, Over Voltage
ChargeCurrent-Max:
2A
BatteryPackVoltage:
4.2V
Voltage-Supply(Max):
16V
Interface:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
