Murata Electronics BLM21PG331SN1D

Part No.:: BLM21PG331SN1D

Manufacturer:: Murata Electronics

Package:: 0805 (2012 Metric)

Datasheet:: BLM21PG331SN1D.pdf

Description:: FERRITE BEAD 330 OHM 0805 1LN

In Stock:: 3720

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BLM21PG331SN1D Specifications

Package/Case:
0805 (2012 Metric)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
EMIFIL®, BLM21
ProductStatus:
Active
FilterType:
Power Line
NumberofLines:
1
Impedance@Frequency:
330 Ohms @ 100 MHz
CurrentRating(Max):
1.5A
DCResistance(DCR)(Max):
70mOhm
Ratings:
-
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount
Height(Max):
0.041 (1.05mm)
Size/Dimension:
0.079 L x 0.049 W (2.00mm x 1.25mm)
