Murata Electronics BLM15EG121SN1D

Part No.:: BLM15EG121SN1D

Manufacturer:: Murata Electronics

Package:: 0402 (1005 Metric)

Datasheet:: BLM15EG121SN1D.pdf

Description:: FERRITE BEAD 120 OHM 0402 1LN

In Stock:: 2361

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BLM15EG121SN1D Specifications

Package/Case:
0402 (1005 Metric)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
EMIFIL®, BLM15
ProductStatus:
Not For New Designs
FilterType:
-
NumberofLines:
1
Impedance@Frequency:
120 Ohms @ 100 MHz
CurrentRating(Max):
1.5A
DCResistance(DCR)(Max):
95mOhm
Ratings:
-
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount
Height(Max):
0.022 (0.55mm)
Size/Dimension:
0.039 L x 0.022 W (1.00mm x 0.55mm)
