Laird Connectivity Inc. BL652-SA-01-T/R

Part No.:: BL652-SA-01-T/R

Manufacturer:: Laird Connectivity Inc.

Package:

Datasheet:: BL652-SA-01-T/R.pdf

Description:: RX TXRX MOD BLUETOOTH CHIP SMD

In Stock:: 2921

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BL652-SA-01-T/R Specifications

Package/Case:
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
RFFamily/Standard:
Bluetooth
Protocol:
Bluetooth v5.0
Modulation:
-
Frequency:
2.4GHz
DataRate:
1Mbps
Power-Output:
4dBm
Sensitivity:
-96dBm
SerialInterfaces:
I²C, SPI, UART
AntennaType:
Integrated, Chip
UtilizedIC/Part:
nRF52832
MemorySize:
512kB Flash, 64kB RAM
Voltage-Supply:
1.7V ~ 3.6V
Current-Receiving:
5.4mA
Current-Transmitting:
5.3mA
MountingType:
Surface Mount

BL652-SA-01-T/R this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including BL652-SA-01-T/R price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for BL652-SA-01-T/R to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

BL652-SA-01-T/R information

Views：

BL652-SA-01-T/R Typical application Circuitry

BL652-SA-01-T R

The BL652-SA-01-T/R is a Bluetooth Low Energy (BLE) module designed by Laird Connectivity, known for its compact size and low power consumption. It supports Bluetooth 5.0, which provides advanced connectivity options including extended range and higher data throughput capabilities. This module is designed for applications requiring wireless communication within the IoT ecosystem, such as industrial automation, smart home devices, and wearable health monitors.

Key Features and Specifications:

- Bluetooth 5.0 Support: Enhances connectivity with longer range and higher speeds.

- Low Power Consumption: Ideal for battery-powered applications where energy efficiency is crucial.

- Compact Size: Its small footprint allows for easy integration into space-constrained devices.

- Flexible I/O Options: Includes a range of GPIOs, UART, I2C, and SPI for interfacing with various peripherals.

- NFC-A Tag Capability: Provides options for touch-to-pair functionalities, simplifying the user interface for device setup.

Application Scenario: Wearable Health Tracker

In this application, the BL652-SA-01-T/R is used within a wearable health tracker designed to monitor vital signs such as heart rate and steps, and communicate this data to a smartphone application for health monitoring.

Circuit Design Methodology:

1. Power Management:

- Battery Power Source: Connect the BL652-SA-01-T/R to a lithium-ion battery with a nominal voltage of 3.7V. Include a voltage regulator to step down the voltage to 3.3V, ensuring stable operation.

- Power Optimization: Implement sleep modes in the firmware to reduce power consumption when the device is inactive.

2. Communication Interfaces:

- UART Communication for Debugging: Establish UART connections (TX, RX) between the BL652-SA-01-T/R and a debugging interface for firmware uploading and diagnostics.

- BLE Configuration: Set up the BLE parameters for secure and reliable data transmission between the health tracker and the smartphone app.

3. Sensor Integration:

- Connecting a Heart Rate Sensor: Utilize one of the GPIOs on the BL652-SA-01-T/R to connect to a heart rate sensor. Configure this pin to handle analog input if necessary.

- Step Counter Interface: Connect a digital accelerometer to another GPIO configured for digital input to track steps and movement.

4. Programming and Firmware Updates:

- SWD Interface for Initial Programming: Ensure that the SWD (Serial Wire Debug) interface is available and properly connected for initial programming. This includes SWCLK and SWDIO pins.

- OTA (Over-the-Air) Updates: Implement a method for OTA updates to allow firmware upgrades without physical access to the device, enhancing user convenience.

5. Testing and Validation:

- Range Testing: Verify the communication range of the BL652-SA-01-T/R within a typical environment to ensure it meets the expected performance criteria.

- Interference Testing: Test the device in areas with potential wireless interference to ensure robust and reliable BLE communication.

Design Considerations:

- Form Factor and Wearability: Design the PCB and device housing to be lightweight and comfortable for continuous wear.

- Security Measures: Incorporate end-to-end encryption for data transmission to protect user data from unauthorized access.

- Regulatory Compliance: Ensure the device complies with FCC, CE, and other relevant wireless communication standards.

- User Interface: Design the companion smartphone app to offer intuitive navigation and clear displays of health data, enhancing the overall user experience.

Integrating the BL652-SA-01-T/R into a wearable health tracker effectively leverages its Bluetooth 5.0 capabilities, low power consumption, and compact form factor. This setup demonstrates how the module can be utilized to provide continuous health monitoring in a user-friendly and energy-efficient manner. The deployment showcases the BL652-SA-01-T/R's adaptability in wearable technology, emphasizing its role in advancing personal health monitoring solutions.
