Silicon Labs BGM113A256V2

Part No.:: BGM113A256V2

Manufacturer:: Silicon Labs

Package:

Datasheet:: BGM113A256V2.pdf

Description:: RX TXRX MOD BLUETOOTH CHIP SMD

In Stock:: 3168

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BGM113A256V2 Specifications

Package/Case:
Packaging:
Strip
Series:
Blue Gecko
ProductStatus:
Active
RFFamily/Standard:
Bluetooth
Protocol:
Bluetooth v4.1
Modulation:
-
Frequency:
2.4GHz
DataRate:
1Mbps
Power-Output:
3dBm
Sensitivity:
-93dBm
SerialInterfaces:
SPI, UART
AntennaType:
Integrated, Chip
UtilizedIC/Part:
EFR32BG
MemorySize:
256kB Flash, 32kB RAM
Voltage-Supply:
3.8V
Current-Receiving:
8.7mA
Current-Transmitting:
8.8mA
MountingType:
Surface Mount
