Name: BCX56-16-TP
Brand: Micro Commercial Co
SKU: BCX56-16-TP
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Micro Commercial Co BCX56-16-TP

Part No.:: BCX56-16-TP

Manufacturer:: Micro Commercial Co

Package:: TO-243AA

Datasheet:: BCX56-16-TP.pdf

Description:: TRANS NPN 80V 1A SOT89

In Stock:: 3735

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCX56-16-TP Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
TransistorType:
NPN
Current-Collector(Ic)(Max):
1 A
Voltage-CollectorEmitterBreakdown(Max):
80 V
VceSaturation(Max)@IbIc:
500mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 2V
Power-Max:
500 mW
Frequency-Transition:
130MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
