Nexperia USA Inc. BCX53-16TX

Part No.:: BCX53-16TX

Manufacturer:: Nexperia USA Inc.

Package:: TO-243AA

Datasheet:: BCX53-16TX.pdf

Description:: TRANS PNP 80V 1A SOT89

In Stock:: 2724

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCX53-16TX Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
1 A
Voltage-CollectorEmitterBreakdown(Max):
80 V
VceSaturation(Max)@IbIc:
500mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 2V
Power-Max:
500 mW
Frequency-Transition:
140MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
