Nexperia USA Inc. BCP56-10T-QF

Part No.:: BCP56-10T-QF

Manufacturer:: Nexperia USA Inc.

Package:: TO-261-4, TO-261AA

Datasheet:: BCP56-10T-QF.pdf

Description:: TRANS NPN 80V 1A SOT223

In Stock:: 3492

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCP56-10T-QF Specifications

Packaging:
Bulk
Series:
Automotive, AEC-Q101, BCP56T-Q
ProductStatus:
Active
TransistorType:
NPN
Current-Collector(Ic)(Max):
1 A
Voltage-CollectorEmitterBreakdown(Max):
80 V
VceSaturation(Max)@IbIc:
500mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
63 @ 150mA, 2V
Power-Max:
600 mW
Frequency-Transition:
155MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
