Name: BCP56-10-TP
Brand: Micro Commercial Co
SKU: BCP56-10-TP
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Micro Commercial Co BCP56-10-TP

Part No.:: BCP56-10-TP

Manufacturer:: Micro Commercial Co

Package:: TO-261-4, TO-261AA

Datasheet:: BCP56-10-TP.pdf

Description:: TRANS NPN 80V 1A SOT223

In Stock:: 2412

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCP56-10-TP Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
TransistorType:
NPN
Current-Collector(Ic)(Max):
1 A
Voltage-CollectorEmitterBreakdown(Max):
80 V
VceSaturation(Max)@IbIc:
500mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
63 @ 150mA, 2V
Power-Max:
1.5 W
Frequency-Transition:
100MHz
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
