Name: BCP53-16T1G
Brand: ON Semiconductor
SKU: BCP53-16T1G
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor BCP53-16T1G

Part No.:: BCP53-16T1G

Manufacturer:: ON Semiconductor

Package:: TO-261-4, TO-261AA

Datasheet:: BCP53-16T1G.pdf

Description:: TRANS PNP 80V 1.5A SOT223

In Stock:: 3578

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCP53-16T1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
1.5 A
Voltage-CollectorEmitterBreakdown(Max):
80 V
VceSaturation(Max)@IbIc:
500mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 2V
Power-Max:
1.5 W
Frequency-Transition:
50MHz
OperatingTemperature:
-65°C ~ 150°C (TJ)
MountingType:
Surface Mount
