Panjit International Inc. BCP53-16-AU_R2_000A1

Part No.:: BCP53-16-AU_R2_000A1

Manufacturer:: Panjit International Inc.

Package:: TO-261-4, TO-261AA

Datasheet:

Description:: TRANS PNP 100V 1A SOT223

In Stock:: 3148

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BCP53-16-AU_R2_000A1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
1 A
Voltage-CollectorEmitterBreakdown(Max):
100 V
VceSaturation(Max)@IbIc:
600mV @ 100mA, 1A
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 2V
Power-Max:
2.6 W
Frequency-Transition:
100MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
