Name: BC846BW/DG/B3X
Brand: Nexperia USA Inc.
SKU: BC846BW/DG/B3X
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nexperia USA Inc. BC846BW/DG/B3X

Part No.:: BC846BW/DG/B3X

Manufacturer:: Nexperia USA Inc.

Package:: SC-70, SOT-323

Datasheet:: BC846BW/DG/B3X.pdf

Description:: TRANS NPN 65V 0.1A SOT323

In Stock:: 3640

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BC846BW/DG/B3X Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
TransistorType:
NPN
Current-Collector(Ic)(Max):
100 mA
Voltage-CollectorEmitterBreakdown(Max):
65 V
VceSaturation(Max)@IbIc:
400mV @ 5mA, 100mA
Current-CollectorCutoff(Max):
15nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
200 @ 2mA, 5V
Power-Max:
250 mW
Frequency-Transition:
100MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
