Nexperia USA Inc. BC846BW/DG/B2,135

Part No.:: BC846BW/DG/B2,135

Manufacturer:: Nexperia USA Inc.

Package:: SC-70, SOT-323

Datasheet:: BC846BW/DG/B2,135.pdf

Description:: TRANS NPN 65V 0.1A SOT323

In Stock:: 3554

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BC846BW/DG/B2,135 Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q101
ProductStatus:
Obsolete
TransistorType:
NPN
Current-Collector(Ic)(Max):
100 mA
Voltage-CollectorEmitterBreakdown(Max):
65 V
VceSaturation(Max)@IbIc:
400mV @ 5mA, 100mA
Current-CollectorCutoff(Max):
15nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
200 @ 2mA, 5V
Power-Max:
200 mW
Frequency-Transition:
100MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
