Name: BC807-25
Brand: Diotec Semiconductor
SKU: BC807-25
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Diotec Semiconductor BC807-25

Part No.:: BC807-25

Manufacturer:: Diotec Semiconductor

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: BC807-25.pdf

Description:: TRANS PNP 45V 0.8A SOT23-3

In Stock:: 3952

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BC807-25 Specifications

Packaging:
Strip
Series:
-
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
800 mA
Voltage-CollectorEmitterBreakdown(Max):
45 V
VceSaturation(Max)@IbIc:
700mV @ 50mA, 500mA
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
160 @ 100mA, 1V
Power-Max:
310 mW
Frequency-Transition:
100MHz
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
