Infineon Technologies AUIPS7081RTRL

Part No.:: AUIPS7081RTRL

Manufacturer:: Infineon Technologies

Package:: PG-TO252-5

Datasheet:: AUIPS7081RTRL.pdf

Description:: IC PWR SWITCH N-CHANNEL 1:1 DPAK

In Stock:: 3655

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AUIPS7081RTRL Specifications

Package/Case:
PG-TO252-5
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Obsolete
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
6V ~ 35V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
2A
RdsOn(Typ):
55mOhm
InputType:
Non-Inverting
Features:
Auto Restart
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
