Broadcom Limited ASSR-1218-503E

Part No.:: ASSR-1218-503E

Manufacturer:: Broadcom Limited

Package:: 4-SOP (0.173, 4.40mm)

Datasheet:: ASSR-1218-503E.pdf

Description:: SSR RELAY SPST-NO 200MA 0-60V

In Stock:: 2731

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ASSR-1218-503E Specifications

Package/Case:
4-SOP (0.173, 4.40mm)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
ASSR
ProductStatus:
Active
MountingType:
Surface Mount
Circuit:
SPST-NO (1 Form A)
OutputType:
AC, DC
Voltage-Input:
1.3VDC
Voltage-Load:
0 V ~ 60 V
LoadCurrent:
200 mA
On-StateResistance(Max):
10 Ohms
TerminationStyle:
Gull Wing

ASSR-1218-503E this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ASSR-1218-503E price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ASSR-1218-503E to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ASSR-1218-503E information

Views：

ASSR-1218-503E Typical application Circuitry Schematics

The ASSR-1218-503E is a Solid State Relay (SSR) designed by Broadcom Limited. It has a high-voltage output detector circuit that is optically connected to an AlGa As infrared LED input stage. The detector consists of a photodiode array, a signal processing circuit, and a power MOS FET. This SSR comes in a 4-pin SOIL package, and it is used in various applications such as telecom switch connections, industrial controls, and office equipment. Let's dive into a unique circuit description:

1. LED Input Pins (1, 2): Pin 1 is the anode and Pin 2 is the cathode of the internal LED. The forward current through the LED will activate it, triggering the rest of the SSR mechanism.

2. MOS FET Output Pins (3, 4): Pin 3 and Pin 4 connect to the drain and source of the internal power MOS FET respectively. When the LED is activated, it triggers the photodiode array, which subsequently activates the MOS FET, allowing current to flow between these two pins.

The output pins are essentially a switch controlled by the input pins, providing electrical isolation between the input and output. Always ensure that the forward current, voltage rating, and power dissipation limits are within the range defined in the data sheet to prevent damage to the device. Also, use a current-limiting resistor in series with the LED to regulate the forward current. The SSR offers advantages of long life, fast switching speed, low electromagnetic interference (EMI), high input-to-output isolation, and low drive power requirements compared to electromagnetic relays. However, the actual usage of these pins and the ASSR-1218-503E may vary based on your specific application. For the most precise information, always refer to the data sheet and other official papers. Should any uncertainties about your design arise, you might want to consult with a professional engineer or participate in a reliable electronics forum.
