Analog Devices Inc. ADXL354CEZ-RL

Part No.:: ADXL354CEZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 14-CLCC

Datasheet:: ADXL354CEZ-RL.pdf

Description:: ACCELEROMETER 2-8G ANALOG 14CLCC

In Stock:: 2376

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADXL354CEZ-RL Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
Type:
Analog
Axis:
X, Y, Z
AccelerationRange:
±2g, 8g
Sensitivity(LSB/g):
-
Sensitivity(mV/g):
400 (±2g) ~ 100 (±8g)
Bandwidth:
1.5kHz
OutputType:
Analog Voltage
Voltage-Supply:
2.25V ~ 3.6V
Features:
Standby Mode
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
